Double direction thrust ball bearings · Designation: 52204
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| d | 15 |
| D | 40 |
| B | 6 |
| Dynamic | 21.2 |
| Static | 37.5 |
| Load limit | 1.4 |
| Reference speed | 4300 |
| Limiting speed | 6000 |
| Mass | 0.15 |
| D1 | 22 |
| r1,2 | 0.6 |
| Da max | 28 |
| ra max | 0.6 |
| r3,4 | 0.3 |
| rb max | 0.3 |
| A | 0.0085 |
| H | 26 |
| da | 20 |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Double direction thrust ball bearings
| Parameter | Value |
|---|---|
| d | 15 |
| D | 40 |
| B | 6 |
| Dynamic | 21.2 |
| Static | 37.5 |
| Load limit | 1.4 |
| Reference speed | 4300 |
| Limiting speed | 6000 |
| Mass | 0.15 |
| D1 | 22 |
| r1,2 | 0.6 |
| Da max | 28 |
| ra max | 0.6 |
| r3,4 | 0.3 |
| rb max | 0.3 |
| A | 0.0085 |
| H | 26 |
| da | 20 |
Parameters as recorded in the source. A missing value is shown as a dash.
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Designation: 52204.
