Single direction thrust ball bearings with a sphered housing washer · Designation: 53202
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| d | 15 |
| D | 32 |
| Dynamic | 15.9 |
| Static | 25 |
| Load limit | 0.915 |
| Reference speed | 7000 |
| Limiting speed | 10000 |
| Mass | 0.063 |
| d1 | 32 |
| D1 | 17 |
| D2 | 24 |
| r1,2 | 0.6 |
| da min | 25 |
| Da max | 24 |
| ra max | 0.6 |
| C | 4 |
| D3 | 35 |
| A | 0.0038 |
| H | 13.3 |
| H1 | 15 |
| Seat washer | U 202 |
| R | 28 |
| s | 12 |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Single direction thrust ball bearings with a sphered housing washer
| Parameter | Value |
|---|---|
| d | 15 |
| D | 32 |
| Dynamic | 15.9 |
| Static | 25 |
| Load limit | 0.915 |
| Reference speed | 7000 |
| Limiting speed | 10000 |
| Mass | 0.063 |
| d1 | 32 |
| D1 | 17 |
| D2 | 24 |
| r1,2 | 0.6 |
| da min | 25 |
| Da max | 24 |
| ra max | 0.6 |
| C | 4 |
| D3 | 35 |
| A | 0.0038 |
| H | 13.3 |
| H1 | 15 |
| Seat washer | U 202 |
| R | 28 |
| s | 12 |
Parameters as recorded in the source. A missing value is shown as a dash.
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Designation: 53202.
