Needle roller bearings with machined rings with flanges, with an inner ring · Designation: NA 6901
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| d | 12 |
| D | 24 |
| B | 22 |
| Dynamic | 16.1 |
| Static | 23.2 |
| Load limit | 2.75 |
| Reference speed | 22000 |
| Limiting speed | 26000 |
| Mass | 0.046 |
| r1,2 | 0.3 |
| da min | 14 |
| Da max | 22 |
| ra max | 0.3 |
| C | – |
| F | 16 |
| s max | 1 |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Needle roller bearings with machined rings with flanges, with an inner ring
| Parameter | Value |
|---|---|
| d | 12 |
| D | 24 |
| B | 22 |
| Dynamic | 16.1 |
| Static | 23.2 |
| Load limit | 2.75 |
| Reference speed | 22000 |
| Limiting speed | 26000 |
| Mass | 0.046 |
| r1,2 | 0.3 |
| da min | 14 |
| Da max | 22 |
| ra max | 0.3 |
| C | – |
| F | 16 |
| s max | 1 |
Parameters as recorded in the source. A missing value is shown as a dash.
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Designation: NA 6901.
