Technical Specifications
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| d | 35 |
| D | 47 |
| Dynamic | 24.6 |
| Static | 45 |
| Load limit | 5.6 |
| Reference speed | 2800 |
| Limiting speed | 5600 |
| Mass | 0.16 |
| D1 | 52.1 |
| D2 | – |
| r1,2 | 0.6 |
| da min | 47.7 |
| ra max | 0.6 |
| C | 30 |
| rb max | 0.3 |
| C1 | 12 |
| C2 | 9 |
| Fw | 35 |
| F | 35 |
| Dynamic axial | 29 |
| Static axial | 93 |
| Load limit axial | 9.15 |
| Minimum load factor | 0.00069 |
| di | 30 |
| Bi | 20 |
| Inner ring | IR 30x35x20 |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
