Technical Specifications
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| d | 260 |
| D | 480 |
| B | 80 |
| Dynamic | 1170 |
| Static | 1700 |
| Load limit | 150 |
| Reference speed | 1400 |
| Limiting speed | 2000 |
| Mass | 68,5 |
| d1 | – |
| D1 | 397 |
| r1,2 | 5 |
| da min | 280 |
| da max | 313 |
| Da max | 460 |
| ra max | 4 |
| kr | 0,15 |
| B1 | – |
| r3,4 | 5 |
| rb max | 4 |
| s | 3,4 |
| F,E | 320 |
| db,Da min | 324 |
| Angle ring | – |
| Mass#2 | – |
| B2 | – |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
