Stainless steel deep groove ball bearings · Designation: W 6000
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| d | 10 |
| D | 26 |
| B | 8 |
| Dynamic | 3.97 |
| Static | 1.96 |
| Load limit | 0.083 |
| Reference speed | 67000 |
| Limiting speed | 40000 |
| Mass | 0.017 |
| d1 | – |
| d2 | 13.9 |
| D1 | – |
| D2 | 22.4 |
| r1,2 | 0.3 |
| da min | 12 |
| da max | – |
| Da max | 24 |
| ra max | 0.3 |
| kr | 0.03 |
| f0 | 12 |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Stainless steel deep groove ball bearings
| Parameter | Value |
|---|---|
| d | 10 |
| D | 26 |
| B | 8 |
| Dynamic | 3.97 |
| Static | 1.96 |
| Load limit | 0.083 |
| Reference speed | 67000 |
| Limiting speed | 40000 |
| Mass | 0.017 |
| d1 | – |
| d2 | 13.9 |
| D1 | – |
| D2 | 22.4 |
| r1,2 | 0.3 |
| da min | 12 |
| da max | – |
| Da max | 24 |
| ra max | 0.3 |
| kr | 0.03 |
| f0 | 12 |
Parameters as recorded in the source. A missing value is shown as a dash.
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Designation: W 6000.
