Drawn cup needle roller bearings · Designation: HK 1012
Parameters as recorded in the source. Missing values are shown as a dash.
| Parameter | Value |
|---|---|
| D | 14 |
| Dynamic | 5.39 |
| Static | 6.95 |
| Load limit | 0.78 |
| Reference speed | 18000 |
| Limiting speed | 20000 |
| Mass | 0.0048 |
| C | 12 |
| Fw | 10 |
| Radial shaft seal | G 10x14x3 |
| Radial shaft seal#2 | – |
| r min | 0.4 |
| Inner ring IR | IR 7x10x12 |
| Inner ring LR | – |
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Drawn cup needle roller bearings
| Parameter | Value |
|---|---|
| D | 14 |
| Dynamic | 5.39 |
| Static | 6.95 |
| Load limit | 0.78 |
| Reference speed | 18000 |
| Limiting speed | 20000 |
| Mass | 0.0048 |
| C | 12 |
| Fw | 10 |
| Radial shaft seal | G 10x14x3 |
| Radial shaft seal#2 | – |
| r min | 0.4 |
| Inner ring IR | IR 7x10x12 |
| Inner ring LR | – |
Parameters as recorded in the source. A missing value is shown as a dash.
A dimensional match does not confirm suitability for a specific application. Execution and operating conditions should be confirmed during selection.
Designation: HK 1012.
